Metamark MD5BO is a gloss white blockout digital film. Offering a high level of performance for medium to long term indoor, outdoor and general signage applications. MD5BO has a grey blockout adhesive to increase opacity and can be applied to most flat or simple curved surfaces. Outstanding print performance with Solvent, Eco Solvent, Latex & UV inkjet printers.
Matching overlaminate the MG700 overlaminate range for extra UV protection.
Features:
- 70 micron
- White Gloss - Blockout
- Permanent grey solvent-based acrylic adhesive
- Layflat kraft liner with PE coating
- Printable with Solvent, Eco Solvent, Latex and U.V. inkjet printers
- Suitable for wet application
- External weathering 7 years (Unprinted)
- Fire Rating Class B - BS EN 13501-1:2018
Class 0 - BS 476 pt7 (glass + Painted 3mm Aliminium)
- REACH and RoHS Compliant.
DOWNLOADS
Data Sheet
FAQs
Adhesive:
- Permanent grey solvent-based acrylic
Release Liner:
- Print ‘Metamark Digital Vinyl’ grey print
- Weight 140 gsm nominal
- Type Layflat kraft with PE coating
Printing and Handling:
- Suitable for use on Solvent, Eco Solvent, Latex and U.V. inkjet printers. Always perform a test print first.
- Ensure that the correct profiles and heater settings are used. Most profiles are available for download from www.metamark.co.uk.
- Ensure that the material has reached room temperature and a relative humidity of 50% before printing.
- Do not handle the face film directly and ensure it is free from dust and static.
Overlaminating:
- Overlamination is recommended to prevent abrasion and to extend colour fastness.
- Allow the inks to cure before overlaminating, this is usually 24-48 hours.
- The matched laminate for MD5-B is MetaGuard 700. For all other laminates the user should determine suitability.
Application:
- Allow the inks to cure before cutting flush to the print, this is usually 24-48 hours.
- Apply unstressed, in particular to curves and recesses. It is not suitable for application over rivets or complex recesses.
- Suitable for wet application. Always apply dry into recesses, and where the print is cut flush, to ensure best adhesion.
- Not recommended for use on low energy surfaces such as polypropylene. The user should determine suitability of substrate
Durability:
- 7 years - (unprinted - European conditions)
